OMAX Digital Microscopes integrate advanced digital-imaging with precision optical-microscopy. Digital integration promotes uniformity and presents a simplified method for setting up and using microscopes.
OMAX provides a large range of solutions for education, research, and industry. Building on industry standards, we provide a full range of accessories to suit your needs.
The OMAX MD8233S50 is a highly versatile, digitally-integrated microscope for laboratories, clinics, and advanced education. Built around a precision, infinity-corrected optical system, this microscope provides excellent ergonomics, smooth mechanics, and expansive scalability. The integrated digital-imaging system further enhances functionality with turnkey efficiency.
Infinity-corrected optics provide better control over optical aberrations, resulting in improved resolution. Four objective lenses and two pairs of eyepieces provide a wide magnification range from 40X to 2000X. With precision mechanics, stage movements and focusing are smooth and reliable. The LED sub-stage lighting provides cool, energy-efficient illumination. Advanced functionality is available with optional dark-field and phase-contrast kits, as well as both mercury and LED-based fluorescence kits.
The integrated 5-megapixel camera can be used for a live video stream, and recording still images and video, all done with a single USB connection. The included Windows software features a wide range of measurement and editing tools, lending itself perfectly to the classroom or clinic with its ability to record, measure, and comment.
Specifications
| Optical System |
Infinity-corrected |
| Head |
Binocular, 30° incline, 360° rotatable |
| Ocular Diameter |
23mm |
| Interpupillary Adjustment |
Siedentopf, 55-75mm |
| Eyepieces |
10X FN18, 20X |
| Nosepiece |
Reverse, Quadruple |
| Objective Lenses |
Achromatic 4X, 10X, 20X, 40X (spring), 100X (spring, oil) |
| Stage |
Double-layer mechanical 140mm x 110mm |
| X-Y Translation Range |
78mm x 46mm |
| Sub-stage Condenser-holder |
Rack-and-pinion |
| Condenser |
Abbe condenser with iris diaphragm, NA1.25 |
| Transmitted Illumination |
LED |
Components
| Eyepieces |
|
| Objective Lenses |
| 4X |
♦ |
| 10X |
♦ |
| 20X |
|
| 40X |
♦ |
| 60X |
|
| 100X |
♦ |
|
| Condenser |
| Abbe Brightfield |
♦ |
| Dry Darkfield |
|
| Oil Darkfield |
|
| Phase-contrast Modular |
|
| Phase-contrast Turret |
|
|
Camera
| Sensor Type |
Shutter |
Optical Format |
Pixels |
| CMOS |
Rolling Shutter |
1/2.5" |
5M (2592x1944) |
Frame Rate(s)
(Maximum) |
SNR |
Power |
Connectivity |
2.5fps @ 2048x1536
10fps @ 1024x768 |
>40dB |
5V over USB |
USB 2.0 |
Software
| OS Requirements |
Windows (32/64 bit) XP/Vista/7/8/10 |
| Hardware Requirements |
Intel Core2 2.8GHz or comparable processor, 2GB RAM, USB2.0 port for maximum speed |
| Features |
| Windows Version |
| Live video preview |
| Captures still images and video |
| Exposure and white-balance controls |
| Image processing |
| Measurement tools, including lines, arcs, polygons |
|
Packing List:
- Digital binocular microscope head
- Microscope body
- 4 objectives: 4X, 10X, 40X, 100X
- A pair of eyepieces WF10X/18
- A pair of eyepieces WF20X
- A bottle of Immersion oil
- Power cord (US and Canada standard)
- Dust cover
- Color filter (green)
- Extra fuse
- Tension wrench
- CD (camera driver and software)
- USB2.0 cable
